Basic terminal SOEHNLE 3010

Features

• Approvable, class III, resolution up to 10.000 e
• Wägebereich 0 – 120.000 kg
• Protection class IP 40 or IP 67
• Backlit LC display, character height: 16 mm
• Three LEDs red / yellow / green as control lights
• Easy 10-key operation
• Functions: Weighing and taring, counting, totalising, order picking, withdrawal weighing, dynamic switching, checking, count checking, dosing
• 1 measuring point included, second measuring point optional
• Integrated power supply, 100 – 240 V AC, 50 –60 Hz

Housing

• Compact housing made from 1.4301 stainless steel, protection class: IP 40, for dry operating conditions protection class IP 67, suited for rough operating conditions
• Optionally available as control cabinet version
• Integrated power supply, cable fed via sealed cable gland
• Pressure is compensated by gas-permeable membrane (IP 67)

Connectivity options

• Up to two analog measuring points can be connected internally
• Approvable resolution up to 10.000 e /3 x 3.000 e with corresponding load cells
• Barcode scanner can be connected via RS 232
• Second display

Interfaces
In total up to 3 peripheral devices can be connected to Terminal 3010. The
following interfaces are optionally available:

• Serial interfaces RS 232, RS 422, RS 485
• USB-interface
• Ethernet
• Profibus DP / Ethernet IP
• I/O card with variable function application, 4 inputs and 6 outputs
• Analog output

Approvable alibi memory via data memory

• Micro SD card with 4 GB storage capacity for 2 million entries (optional)

ATEX zone

• The Basic Terminal 3010 is optionally available as ATEX version for use in ATEX zone 2/22
